C-Frame Downspray Assembly

This pre-assembled kit makes adding emitters incredibly easy.

Step 1: Puncture Your Mainline
Using a DripWorks key punch or pocket punch, create a clean hole in your 1/2-inch poly mainline tubing near your plant container.

Step 2: Connect the Assembly
Take the pre-installed 1/4-inch transfer barb at the end of the 36-inch micro tubing and press it firmly into the punched hole until it clicks.

Step 3: Position the Stake
Push the 12-inch wire stake into the soil of your container, ensuring the C-Frame sprayer head is centered for even downward coverage.

Step 4: Control the Flow
Use the included shutoff clip on the micro tubing to turn the water off if the container is empty or during periods of heavy rain.

Is the C-Frame Down-Spray Assembly good for spring planting in large pots?
Yes, the C-Frame Down-Spray Assembly is excellent for spring containers. It delivers a fine, 20-inch downward spray that thoroughly wets the root zone without disturbing fresh soil or delicate new foliage.

Proper hydration early in the growing season guarantees your roots establish quickly and strongly before summer heat arrives.

Does the C-Frame Down-Spray Assembly come with tubing and connectors?
Yes, this assembly is completely ready to install. It includes the sprinkler head, a 12-inch wire stake, 36 inches of micro tubing, and a pre-installed transfer barb for immediate connection.

How do I stop watering an empty pot with the C-Frame Down-Spray Assembly?
Each assembly includes a built-in shutoff clip on the tubing. If you remove a plant or a container is empty, simply engage the clip to completely stop the water flow.

What pressure is recommended for the C-Frame Down-Spray Assembly?
For optimal performance and an even 20-inch spray pattern, we recommend operating this emitter between 10 and 20 PSI. Using a standard pressure regulator on your mainline system is highly advised.
